Product Features

●Supports 1.06 to 10.5Gb/s bit rates per Channel

●Four-Channel ,1x12 MPO receptacle

●Hot pluggable QSFP+ form factor

●VCSEL 850nm array Technology

●Applicable for 100m&300m on OM3 MMF,150m&400m on OM4 MMF.

●Built-in digital diagnostic functions

●Low power consumption, < 1.5W

●Unretimed XLPPI electrical interface

●Operating case temperature: -5°C to 80 °C

Applications

●40GBASE-SR4 40G Ethernet

●Datacom/Telecom switch & router connections

●Data Aggregation and Backplane Applications

●Proprietary Protocol and Density Applications

●Infiniband transmission at 4CH SDR, DDR and QDR

●Other optical links

Product Descriptions

CDS1&3 is a Four-Channel, Pluggable, Parallel, Fiber-Optic QSFP+ Transceiver for 40 Gigabit Ethernet Applications. This transceiver is a high performance module for short-range multi-lane data communication and interconnect applications. It integrates four data lanes in each direction with 40 Gbps bandwidth.one version is Each lane can operate at 10.5Gbps up to100m using OM3 or 150m using OM4 Multimode fiber,another version is Each lane can operate at 10.5Gbps up to300m using OM3 or 400m using OM4 Multimode fiber These modules are designed to operate over multimode fiber systems using a nominal wavelength of 850nm. The electrical interface uses a 38 contact edge type connector. The optical interface uses an 12 fiber MTP (MPO) connector. This module incorporates proven circuit and VCSEL technology to provide reliable long life, high performance, and consistent service.

 Package



Ordering Information



Part No.	Data Rate	DDM	Wavelength	Fiber Type	Dist.	Optical Interface
QSFP-SR-100M	40Gbps	yes	850nm	MMF	100M	MPO
QSFP-SR-300M	40Gbps	yes	850nm	MMF	300M	MPO
QSFP-LR	40Gbps	yes	1310nm	SMF	10KM	MPO
QSFP-ER4	40Gbps	yes		SMF	40KM	MPO
