PRODUCT FEATURES

l Up to 10.7Gbps Data Links

l Single Mode LC Receptacle Bi-directional Transceiver

l Up to 60km transmission on SMF

l Power dissipation<1.5W

l 1270nm DFB laser and 1330nm PIN receiver

l 2-wire interface with integrated Digital Diagnostic monitoring

l EEPROM with Serial ID Functionality

l Compliant with FC_PI_4 REV 7.0

l Compliant with XFP MSA with duplex LC connector

l Single + 3.3V Power Supply and LVTTL Logic

l Operating case temperature:0~+70ºC

APPLICATIONS

l 10GBASE-BX 10.3125Gb/s Ethernet

l 10GBASE-BX 9.953Gb/s Ethernet

l SONET OC-192 SR-1 SDH STM I-64.1

PRODUCT DESCRIPTION

BIDI-XFP-ZR-27 is hot pluggable 3.3V Small-Form-Factor transceiver module. It designed expressly for high-speed communication applications that require rates up to 10.7Gb/s, it designed to be compliant with XFP MSA. The module data link up to 60km in 9/125um single mode fiber.

The optical output can be disabled by a LVTTL logic high-level input of Tx Disable. Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner.

 Package
