1.25G BIDI SC SFP
- Brand: NVOC
- Type: NV-OC24A/BS
Features
►Dual data-rate of 1.25Gbps/1.063Gbps operation
►1310nm FP laser and PIN photodetector for 10km transmission
►Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
►Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
►Compatible with SONET OC-24-LR-1
►Compatible with RoHS
►+3.3V single power supply
►Operating case temperature:
Standard : 0 to +70°C
Applications
►Gigabit Ethernet
►Fiber Channel
►Switch to Switch interface
►Switched backplane applications
►Router/Server interface
►Other optical transmission systems
Description
The BIDI SFP transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 10km transmission distance with SMF.
The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
Package
|
Part Number |
Product Description |
|
OC24-3AS |
1310nm, 1.25Gbps, SC,3km, 0°C~+70°C |
|
OC24-3ASD |
1310nm, 1.25Gbps, SC,3km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-3A |
1310nm, 1.25Gbps, LC,3km, 0°C~+70°C |
|
OC24-3AD |
1310nm, 1.25Gbps, LC,3km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
Part Number |
Product Description |
|
OC24-20AS |
1310nm, 1.25Gbps, SC,20km, 0°C~+70°C |
|
OC24-20ASD |
1310nm, 1.25Gbps, SC,20km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-20A |
1310nm, 1.25Gbps, LC,20km, 0°C~+70°C |
|
OC24-20AD |
1310nm, 1.25Gbps, LC,20km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
Part Number |
Product Description |
|
OC24-40AS |
1310nm, 1.25Gbps, SC,40km, 0°C~+70°C |
|
OC24-40ASD |
1310nm, 1.25Gbps, SC,40km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-40A |
1310nm, 1.25Gbps, LC,40km, 0°C~+70°C |
|
OC24-40AD |
1310nm, 1.25Gbps, LC,40km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
Part Number |
Product Description |
|
OC24-60AS |
1310nm, 1.25Gbps, SC,60km, 0°C~+70°C |
|
OC24-60ASD |
1310nm, 1.25Gbps, SC,60km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-60A |
1310nm, 1.25Gbps, LC,60km, 0°C~+70°C |
|
OC24-60AD |
1310nm, 1.25Gbps, LC,60km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
Part Number |
Product Description |
|
OC24-80AS |
1490nm, 1.25Gbps, SC,80km, 0°C~+70°C |
|
OC24-80ASD |
1490nm, 1.25Gbps, SC,80km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-80A |
1490nm, 1.25Gbps, LC,80km, 0°C~+70°C |
|
OC24-80AD |
1490nm, 1.25Gbps, LC,80km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
Part Number |
Product Description |
|
OC24-100AS |
1490nm, 1.25Gbps, SC,100km, 0°C~+70°C |
|
OC24-100ASD |
1490nm, 1.25Gbps, SC,100km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-100A |
1490nm, 1.25Gbps, LC,100km, 0°C~+70°C |
|
OC24-100AD |
1490nm, 1.25Gbps, LC,100km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
Part Number |
Product Description |
|
OC24-120AS |
1490nm, 1.25Gbps, SC,120km, 0°C~+70°C |
|
OC24-120ASD |
1490nm, 1.25Gbps, SC,120km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-120A |
1490nm, 1.25Gbps, LC,120km, 0°C~+70°C |
|
OC24-120AD |
1490nm, 1.25Gbps, LC,120km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
Part Number |
Product Description |
|
OC24-140AS |
1490nm, 1.25Gbps, SC,140km, 0°C~+70°C |
|
OC24-140ASD |
1490nm, 1.25Gbps, SC,140km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-140A |
1490nm, 1.25Gbps, LC,140km, 0°C~+70°C |
|
OC24-140AD |
1490nm, 1.25Gbps, LC,140km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
Part Number |
Product Description |
|
OC24-160AS |
1490nm, 1.25Gbps, SC,160km, 0°C~+70°C |
|
OC24-160ASD |
1490nm, 1.25Gbps, SC,160km, 0°C~+70°C, With Digital Diagnostic Monitoring |
|
OC24-160A |
1490nm, 1.25Gbps, LC,160km, 0°C~+70°C |
|
OC24-160AD |
1490nm, 1.25Gbps, LC,160km, 0°C~+70°C, With Digital Diagnostic Monitoring |
